lwclancers
New Member
That came out well! Was it as hard as everyone has been saying?
Sent from my HTC6435LVW using Tapatalk 2
Sent from my HTC6435LVW using Tapatalk 2
Seat Covers - Install pics
- Thread starter JT
- Start date
TWSS lmfao sorry I had to
Thanks again Jt, I have Tapatalk now but I started messing with my seat.
1.I cut into a 2" piece of rebond to fit onto the seatpan properly.
2.I glued another piece of 2" rebond on top of it to get the height needed near the tank, then I rounded off the edges to get the proper shape.
3.Cut the gelpad from LuiMoto into the rebond.
4.I glued 1" of high density foam over everything before installing the cover.
It feels great now, I can't feel the seatpan anywhere.I lost a little rise near the front (although the front is 1" taller).Its like I added 50% foam up front and 100% in the rear, but it was all I could fit into the front of the seat cover.It isn't a big deal to me though because im tall and sit towards the back of the seat anyway.If I need more rise I can shim up the front of the seatpan, or file down the rubber legs a little to drop the back.Its to comfortable to care much though.
lwclancers
New Member
Got my foam cut and gel pad inserted today. But the 6mm staples don't fit my staple gun, sigh. Might not have time to go to the store tmw, might be another week until mine is ready to go
Sent from my HTC6435LVW using Tapatalk 2
Sent from my HTC6435LVW using Tapatalk 2
that looks SWEET!Here is mine all installed...have yet to ride afraid of getting the white dirty.
Plus it looks so good, thinking of selling the bike to Barbers Moto Museum
I'm actually debating re-doing it just to replace all the foam under and plush it up a little, but that can wait till winter time.
linkgt
Member
Took some pics of my seats. not the best, but decent. I like how they match with the CF where you rest your knee and the tank pad
[URL=http://imageshack.com/i/nl3wopj/]
[URL=http://imageshack.com/i/nl3wopj/]
Last edited:
lwclancers
New Member
Finally got to my front yesterday and today. I won't lie, I'm scared to do the back seat, sigh.
Some gel install pics, then the front. Really had some issues with staples, I probably trashed more than I actually got to stick. Using large paper binder clips really helped.
I think the color choices work well, with the white lacing. My original was a stock red seat....
Sent from my HTC6435LVW using Tapatalk 2
Some gel install pics, then the front. Really had some issues with staples, I probably trashed more than I actually got to stick. Using large paper binder clips really helped.
I think the color choices work well, with the white lacing. My original was a stock red seat....
Sent from my HTC6435LVW using Tapatalk 2
Attachments
Looks good, now you just need some carbon fiber mirrors.
lwclancers
New Member
I do And I have it on my exhaust too.
Sent from my HTC6435LVW using Tapatalk 2
And I have it on my exhaust too. Sent from my HTC6435LVW using Tapatalk 2
I do
Sent from my HTC6435LVW using Tapatalk 2
You have the same mirrors I do then. I love them!
lwclancers
New Member
So for everyone who did their own, when you did the rear seat, which end did you staple/start at first? For over an hour now and don't even have one staple in. Maybe its me, but it doesn't seem to be fitting right, but maybe I'm starting it wrong. Seems to be more material stretching underneath as compared to the front seat
Sent from my HTC6435LVW using Tapatalk 2
Sent from my HTC6435LVW using Tapatalk 2
lwclancers
New Member
This dry fit doesnt look right at all...so much extra fabric in the front, but I swear its the right spot for the seams. Kind of frustrated
Sent from my HTC6435LVW using Tapatalk 2
Sent from my HTC6435LVW using Tapatalk 2
Attachments
lwclancers
New Member
Anyone...Bueller? Ferris Bueller?
Totally lost and frustrated on this rear seat. Im worried I might have to send this back to Luimoto, but want to make sure I tried the same process that others have tried here.
Totally lost and frustrated on this rear seat. Im worried I might have to send this back to Luimoto, but want to make sure I tried the same process that others have tried here.
